MODEL

UNT

1676

1876

2076

Table

Table Size

mm

1700 x 760

1900 x 760

2100 x 760

Working Area

mm

1600 x 760

1800 x 760

2000 x 760

T - Slot

mm

18 x 7 x 100

18 x 7 x 100

18 x 7 x 100

Max. Table Loading Capacity

kgs

1800

2100

2400

Travel

X/Y/Z - Axis Travel

mm

1600/ 760 /700

1800 / 760 / 700

2000 / 760 /700

Spindle Nose To Table Surface

mm

140 ~ 840

Spindle

Spindle Taper

ISO 40(ISO 50)

Spindle Speed

rpm

8000 (10000,12000,15000 ) (ISO50: 6000,8000,10000)

Transmission Method

Belt (Direct, Gearbox)

Spindle Motor

kw

11/15 (15/18.5)

ATC

Magazine Capacity

tools

24 (30,32,36) (ISO50: 20,24)

Tool Selection Method

Random

Max. Diameter / W / O (Adjacent)

mm

Ø75 / Ø150

Max. Tool Weight / Length

kgs/mm

7 / 300 (ISO50: 15/350)

Tool Shank Specification

ISO-40 (ISO-50)

Tool Change Time

sec

T-T 2.5; C-C 4.8

3 Axis Traverse

3 Axis Cutting Feedrate

mm/min

12000

3 Axis Rapid Traverse

m/min

24/24/24 (30/30/24)

Drive Motors

Chip Auger Mmotor

hp

1/4

Chip Conveyor Motor

hp

1/4

Coolant Pump Motor

hp

3/4

Chip Flushing Pump Motor

hp

1/2 (3/4)

Coolant Tank

Coolant Tank Capacity

l

480

500

520

Coolant Flow

l/min

200

200

200

Others

Machine Dimensions (LxWxH)

mm

4610 x3470 x3190

4970x3470x3190

5440x3470x3190

Net Weight / Gross Weight

kgs

8700/9300

9100/9700

10000/10600
